Model
|
GWGJ-BPDU-C19-15
|
|
Input voltage
|
240V Single phase(LNG) to 240V single phase
|
|
|
380V 3phase(LLLNG) to 220V single phase.
|
|
|
415v 3phase(LLLNG) to 240V single phase
|
|
|
480V 3phase(LLLNG) to 277V single phase.
|
|
input connector
|
63A x 5 wires(or juction box, input breaker optional,price difference)
|
|
Frequency
|
50/60Hz
|
|
Total current
|
Max 63A
|
|
Rating output voltage
|
208~300VAC
|
|
Max output power for each outlet
|
Under 208V,Max 2080W per outlet
|
|
Under 240V,Max 2400W per outlet
|
|
Under 277V,Max 2770W per outlet
|
|
Total output power
|
Max 2770W x 24
|
|
Socket standard
|
15pcs C19 (can be changed as client request)
|
|
Color
|
black/optional
|
|
Size
|
1185*85*75mm
|
|
Net Weight
|
8kg
|
|
Shell material
|
Aluminum Alloy
|
